#40 H Bushed 24 Teeth

Item ID: 40H24HT
40 Pitch, H Bushing Split Taper Sprocket, 24 Teeth Hardened

UPS SKU: 4903863144392
Bore:

Technical Specification

Part No.: 40H24H
Teeth: 24
Type: B3
Bushing: H
OD: 4.1
PD: 3.831
max bore d: 1-1/2
L1: 1-1/2
L: 1-1/4
B: 1-1/32
C: 1/16
HD: 2-1/2
App. Wt. (lbs): 1.2
