#40 Taper Bushed Sprocket 24 Teeth

Item ID: 40BTL24HT
40 Pitch, 1610 Bushing Taper Bushed Sprocket, 24 Teeth Hardened

UPS SKU: 4903863143753
Bore:

Technical Specification

Part No.: 40BTB24H
Type: Single Taper-Bushed B
Teeth: 24
Bushing: 1610
OD: 4.098
PD: 3.831
max bore d: 1-5/8
HD: 3-1/4
L: 1
Sprocket Wt (lbs): 1.4
Bushing Wt (lbs): 0.9
