#100 Taper Bushed Sprocket 19 Teeth

Item ID: 100BTL19HT
100 Pitch, 2517 Bushing Taper Bushed Sprocket, 19 Teeth Hardened

UPS SKU: 4903863130333
Bore:

Technical Specification

Part No.: 100BTB19H
Type: Single Taper-Bushed
Teeth: 19
Bushing: 2517
OD: 8.241
PD: 7.594
max bore d: 2-1/2
HD: 4-1/2
L: 1-3/4
Sprocket Wt (lbs): 8.7
Bushing Wt (lbs): 3.5
