#80 Taper Bushed Sprocket 24 Teeth

Item ID: 80BTL24HT
80 Pitch, 2517 Bushing Taper Bushed Sprocket, 24 Teeth Hardened

UPS SKU: 4903863161368
Bore:

Technical Specification

Part No.: 80BTB24H
Type: Single Taper-Bushed B
Teeth: 24
Bushing: 2517
OD: 8.196
PD: 7.661
max bore d: 2-1/2
HD: 4-1/4
L: 1-3/4
Sprocket Wt (lbs): 7.5
Bushing Wt (lbs): 3.5
