#40 P Bushed 24 Teeth

Item ID: 40P24HT
40 Pitch, P Bushing Split Taper Sprocket, 24 Teeth Hardened

UPS SKU: 4903863144552
Bore:

Technical Specification

Part No.: 40P24H
Teeth: 24
Type: B4
Bushing: P1
OD: 4.1
PD: 3.831
max bore d: 1-3/4
L1: 2-3/16
L: 1-15/16
B: 1-21/32
C:
HD: 3
App. Wt. (lbs): 1.8
