#40 H Bushed 20 Teeth

Item ID: 40H20HT
40 Pitch, H Bushing Split Taper Sprocket, 20 Teeth Hardened

UPS SKU: 4903863144378
Bore:

Technical Specification

Part No.: 40H20H
Teeth: 20
Type: B3
Bushing: H
OD: 3.45
PD: 3.196
max bore d: 1-1/2
L1: 1-1/2
L: 1-1/4
B: 1-1/32
C: 1/16
HD: 2-1/2
App. Wt. (lbs): 0.8
