#100 E Bushed QD 24 Teeth

Item ID: 100E24HT
100 Pitch, E Bushing QD Sprocket, 24 Teeth Hardened

UPS SKU: 4903863130579
Bore:

Technical Specification

Part No.: 100E24H
Type: Single Q-bushed
Teeth: 24
Bushing: E
OD: 10.25
PD: 9.577
max bore d: 3-1/2
L1: 2-5/8
L2: 2-15/16
HD: 6
A: 1-13/16
C: 15/16
L: 1-5/8
App Wt with Hub (lbs): 25.7
App Sprocket Wt (lbs): 15.7
