#100 B Hub 9 Teeth

Item ID: 100B09HT
100 Pitch, B Hub, 9 teeth hardened

UPS SKU: 4903863128934
Bore:

Technical Specification

Part No.: 100B09H
Type: Single Type B
Teeth: 9
OD: 4.180
PD: 3.655
d max: 1-5/8
d min: 1
HD: 2-13/16*
L: 1-7/8
GD: 2.169
App. Wt. (lbs): 3.2
Note: *Hub has recessed groove allowing for chain clearance.
